IKEDA Single-Use Bronchoscopes include seven distinct models, offering the necessary variety and convenience in choice. This product series features an HD image with a 120°(130°) Field of view, 5-50(100)mm Depth of field , and a dedicated design that allows small angulation radius, high force transmission ratio, and stepless angulation control. Our premium single-use bronchoscopes enable you to effectively mitigate the risks associated with cross-contamination and subsequent infection during diagnostic and therapeutic procedures.
| Model | Insertion Tube | Distal End | Channel Size | Resolution | Working Length | Bending | Field of View | Depth of Field |
| C2 | 2.5mm | 2.8mm | 1.2mm | 160,000 | 600mm |
UP＞210° DOWN＞210° |
120° | 5-50mm |
| C3 | 3.1mm | 3.2mm | 1.2mm | 160,000 | 600mm |
UP＞210° DOWN＞210° |
120° | 5-50mm |
| C4 | 4.5mm | 4.7mm | 2.2mm | 160,000 | 600mm |
UP＞210° DOWN＞210° |
120° | 5-50mm |
| C5 | 5.3mm | 5.4mm | 2.8mm | 160,000 | 600mm |
UP＞210° DOWN＞210° |
120° | 5-50mm |
| C6 | 5.7mm | 5.9mm | 3.2mm | 160,000 | 600mm | UP＞210° DOWN＞210° | 120° | 5-50mm |
| C7 | 6.2mm | 6.4mm | 2.8mm | 1000,000 | 600mm | UP＞210° DOWN＞210° | 130° | 4-80mm |
| C8 | 2.0mm | 2.0mm | / | 160,000 | 600mm | UP＞210° DOWN＞210° | 120° | 5-50mm |
